Tenda AC7 Broadband Wireless Router 1200m Dual-Band Gigabit Wifi Signal Through The Wall King English Version

Product Information

Product size 220*141.5*49mm

Hardware Specifications

• Wired standard IEEE802.3, IEEE802.3u
• Interface 10/100Mbps WAN port*1
• 10/100Mbps LAN ports*3
• Antenna 6dBi external dual-band omnidirectional antenna*5
• Button WiFi on/off*1, WPS/Reset button*1
• Power Output: DC 9V1A
• Weight Net weight: 314g Gross weight: 756g
• Panel light System*1, WAN*1, LAN*1, WiFi*1

Software Specifications

• Broadband access mode PPPoE, Dynamic IP, Static IP
• Working Mode Wireless Router Mode
• AP mode
• Wireless relay mode (Client+AP, WISP)
• DHCPDHCP server
• DHCP client list
• DHCP static IP address reservation and assignment
• Virtual server port forwarding
• DMZ host
• UPnP
• Security Client Filtering (Black and White List Filtering)
• Parental Controls (URL Filtering)
• Remote WEB management
• Firewall anti-WAN port PING disable/enable
• Anti-UDP packet flooding
• Anti-TCP packet flooding
• Anti-ICMP packet flooding
• Support IPsec, PPTP, L2TP penetration
• DDNS supports DynDNS, 88ip, peanut shell
• Features Automatic migration technology of broadband accounts
• WiFi timer switch
• Smart power saving
• panel light switch
• Tenda App local and remote management

Wireless Specifications

• Wireless standard IEEE 802.11/a/n/ac wave2 @ 5GHz
• IEEE 802.11b/g/n @2.4GHz
• Wireless rate 5GHz: 867Mbps
• 2.4GHz: 300Mbps
• Wireless Band 2.4GHz & 5GHz
• Transmission power standard 2.4GHZ:
• 18dbm@MCS7
• 19dbm@OFDM 54M
• 22dbm@CCK 11M
• 5GHz:
• 17dbm@MCS9
• 19dbm@OFMD 54M
• Basic functions support SSID broadcasting and hiding
• Support signal strength adjustment
• Featured technology supports MU-MIMO technology
• Support Beamforming+ signal directional transmission technology
• Wireless encryption method WPA-PSK/WPA2-PSK, WPA/WPA2
• Wireless encryption disable and enable
• WPS fast and secure connection

Other specifications

• Other bandwidth controls
• guest network
• IPTV
• MAC address cloning
• System log
• Configuration backup and restore
• Online upgrade (new version push and online detection)
• Ambient temperature Working temperature: 0℃ ~ 40℃
• Storage temperature: -40℃ ~ 70℃.
• Ambient humidity Working humidity: 10% ~ 90% RH non-condensing
• Storage humidity: 5% ~ 90%RH non-condensing
• Factory default setting Default access address: tendawifi.com
• Certification 3C/FCC/CE/ROHS
• Package Contents One 1200M 11ac Dual Band Wireless Router
• A power adapter
• Installation Guide

Note: MOQ --- 4pcs
