Main Specification

• Basic paving width (m): 1.2~2.2

• Max.paving width (m): 3.5

• Max.paving thickness (mm): 200

• Working speed (m/min): 0~25

• Travel speed (km/h): 0~3.6

• Theoretical productivity (t/h): 300

• Hopper capacity (t): 5.8

• Gradeability (%): 20

• Evenness (mm/3m): 3

• Crown adjustment range (%): -2~+4

• Diesel engine power (kw): 53

• Diesel engine speed (r/min): 2200

• Conveying speed (m/min): 0~25

• Distributing speed (r/min): 0~70

• Tamper speed (r/min): 0~1500

• Overal imension (mm): 4910*1400*1935

• Total weight (t): 7.5

• Diesel tank volume (L): 100

• Hydraulic tank volume (L): 80
