Sophia
Gas 4 Burner Range
Specifications
Model: YDRS-4E(With Electric Oven)
Overrall dimension (mm): 800x900x(850+70)
Internal Dimension of oven (mm): 568x590x270
LPG/2800Pa Kg/h Gas consumption: 4.15
NG/2000Pa Kg/h Gas consumption: 5.85
KW Power Supply LPG: 5x4=20
KW Power Supply NG: 7.75x4=31
380/50-60Hz
Gas Connection: R1 3/4
Package Size (mm): 1020x880x1120
N/W (KG): 120.00
G/W (KG): 186.00
Model: YDTQ-4E(With Electric Oven)
Overrall dimension (mm): 700x700x(850+70)
Internal Dimension of oven (mm): 568x590x270
LPG/2800Pa Kg/h Gas consumption: 2.4
NG/2000Pa Kg/h Gas consumption: 3.49
KW Power Supply LPG: 5x4=20
KW Power Supply NG: 7.75x4=31
380/50-60Hz
Gas Connection: R1 3/4
Package Size (mm): 830x730x1120
N/W (KG): 105.00
G/W (KG): 151.00
Model: YDRS-4 (With Oven)
Overrall dimension (mm): 800x900x(850+70)
Internal Dimension of oven (mm): 568x590x270
LPG/2800Pa Kg/h Gas consumption: 2.15
NG/2000Pa Kg/h Gas consumption: 3.89
KW Power Supply LPG: 5x4+5.8=25.8
KW Power Supply NG: 7.75x4+5.8=36.8
Gas Connection: R1 3/4
Package Size (mm): 1020x880x1120
N/W (KG): 121.00
G/W (KG): 187.00
Model: YDTQ-4 (With Oven)
Overrall dimension (mm): 700x700x(850+70)
Internal Dimension of oven (mm): 568x590x270
LPG/2800Pa Kg/h Gas consumption: 2.15
NG/2000Pa Kg/h Gas consumption: 3.89
KW Power Supply LPG: 5x4+5.8=25.8
KW Power Supply NG: 7.75x4+5.8=36.8
Gas Connection: R1 3/4
Package Size (mm): 830x780x1120
N/W (KG): 110.00
G/W (KG): 152.00
Model: YDRS-4A With Cabrnet
Overrall dimension (mm): 800x900x(850+70)
Internal Dimension of oven (mm):
LPG/2800Pa Kg/h Gas consumption: 2.06
NG/2000Pa Kg/h Gas consumption: 3.07
KW Power Supply LPG: 5x4=20
KW Power Supply NG: 7.75x4=31
Gas Connection: R1 3/4
Package Size (mm): 1020x880x1120
N/W (KG): 93.00
G/W (KG): 195.00
Model: YDTQ-4A With Cabrnet
Overrall dimension (mm): 700x700x(850+70)
Internal Dimension of oven (mm):
LPG/2800Pa Kg/h Gas consumption: 2.06
NG/2000Pa Kg/h Gas consumption: 3.07
KW Power Supply LPG: 5x4=20
KW Power Supply NG: 7.75x4=31
Gas Connection: R1 3/4
Package Size (mm): 830x780x1120
N/W (KG): 81.00
G/W (KG): 127.00
Model: YDRA-4 With Oven (European burner)
Overrall dimension (mm): 800x900x(850+70)
Internal Dimension of oven (mm): 568x590x270
LPG/2800Pa Kg/h Gas consumption: 2.93
NG/2000Pa Kg/h Gas consumption: 4.1
KW Power Supply LPG: 5.6x2+9x2+5.8=35
KW Power Supply NG: 7.75x2+9x2+5.83=39.3
Gas Connection: R1 3/4
Package Size (mm): 1020x880x1120
N/W (KG): 123.00
G/W (KG): 89.00
Model: YDTA-4 With Oven (European burner)
Overrall dimension (mm): 700x700x(850+70)
Internal Dimension of oven (mm): 568x590x270
LPG/2800Pa Kg/h Gas consumption: 2.93
NG/2000Pa Kg/h Gas consumption: 4.1
KW Power Supply LPG: 5.6x2+9x2+5.8=35
KW Power Supply NG: 7.75x2+9x2+5.83=39.3
Gas Connection: R1 3/4
Package Size (mm): 830x780x1120
N/W (KG): 108.00
G/W (KG): 154.00
Model: YDRA-4A With Cabinet (European Furnace Head)
Overrall dimension (mm): 800x900x(850+70)
Internal Dimension of oven (mm):
LPG/2800Pa Kg/h Gas consumption: 1.73
NG/2000Pa Kg/h Gas consumption: 2.33
KW Power Supply LPG: 5.6x2+9x2=29.2
KW Power Supply NG: 7.75x2+9x2=33.5
Gas Connection: R1 3/4
Package Size (mm): 1020x880x1120
N/W (KG): 95.00
G/W (KG): 161.00
Model: YDTA-4A With Cabinet (European Furnace Head)
Overrall dimension (mm): 700x700x(850+70)
Internal Dimension of oven (mm):
LPG/2800Pa Kg/h Gas consumption: 1.73
NG/2000Pa Kg/h Gas consumption: 2.33
KW Power Supply LPG: 5.6x2+9x2=29.2
KW Power Supply NG: 7.75x2+9x2=33.5
Gas Connection: R1 3/4
Package Size (mm): 830x780x1120
N/W (KG): 83.00
G/W (KG): 129.00
